Zusuka VRV/VRF Systems | Smart Cooling for Large Projects

Welcome to Zusuka VRV Air Conditioners

Engineered for powerful and efficient climate control in commercial environments, our VRV air conditioners provide 360° air distribution, silent operation, and seamless ceiling integration. Ideal for offices, showrooms, and institutional spaces.

Advantages of VRV Technology

High energy savings – up to 55%
Individual zone control
Wide range of indoor unit compatibility
Reduced installation space
Silent outdoor operation
Built-in diagnostics and automation

Copper Piping Distance

Zusuka VRV systems are engineered for ultimate flexibility in large-scale installations. With industry-leading copper piping capabilities, our systems support:

Horizontal piping lengths up to 120 meters
Vertical elevation differences up to 50 meters

This extended piping distance makes Zusuka VRV systems the ideal solution for high-rise buildings, sprawling commercial complexes, hospitals, hotels, and multi-story offices—delivering consistent, efficient climate control without compromise.

Our advanced piping design ensures:

Minimal energy loss
Stable refrigerant flow
Reliable performance across long distances

Choose Zusuka for powerful performance even in the most challenging architectural layouts.

Multiple Indoor Unit Connectivity

Zusuka VRV systems offer exceptional flexibility by allowing connection of up to 64 indoor units to a single outdoor unit. This advanced connectivity is designed to meet the demands of modern infrastructure, where comfort and efficiency are both essential.

Where It Works Best:

Malls: Enable climate control for multiple stores and zones independently
Hotels: Offer personalized comfort for each room with individual control
Hospitals: Maintain precise temperatures in wards, ICUs, and labs
Corporate Offices: Ensure consistent performance across departments and floors

This capability reduces the number of outdoor units required, saving on:

Installation space – fewer units outside the building
Visual clutter – a more aesthetically clean exterior
Operational cost – one high-efficiency outdoor unit serving multiple rooms

Intelligent Control Options:

Individual remote control for each indoor unit
Centralized controller for building management systems (BMS)
Scheduling and automation capabilities

Zusuka's flexible piping design also allows each indoor unit to be placed at different heights and distances, offering true design freedom for architects and consultants.

Result: Reduced complexity, superior energy efficiency, and enhanced occupant comfort in every zone.

Zusuka VRV Outdoor Unit Capacities

Zusuka Model	HP	Cooling Capacity (kW)	Power Input (kW)	EER (W/W)	COP
ZVRV06	6	16.0	4.59	3.49	3.49
ZVRV08	8	22.4	6.14	3.65	3.65
ZVRV10	10	28.0	7.72	3.63	3.63
ZVRV12	12	33.5	9.40	3.57	3.57
ZVRV14	14	40.0	10.96	3.65	3.65
ZVRV16	16	45.0	12.32	3.65	3.65
ZVRV18	18	50.0	13.73	3.64	3.64
ZVRV20	20	56.0	15.40	3.64	3.64
ZVRV22	22	61.5	16.86	3.65	3.65
ZVRV24	24	67.0	18.34	3.65	3.65
ZVRV26	26	73.5	19.82	3.71	3.71
ZVRV28	28	78.0	21.27	3.67	3.67
ZVRV30	30	84.0	22.75	3.69	3.69
ZVRV32	32	90.0	24.18	3.72	3.72
ZVRV34	34	95.0	25.64	3.71	3.71
ZVRV36	36	100.0	27.10	3.69	3.69
ZVRV38	38	106.0	28.60	3.71	3.71
ZVRV40	40	112.0	30.05	3.73	3.73

Note: 1 HP ≈ 0.75 TR. Zusuka uses advanced Japanese & German inverter technology to ensure high performance and energy savings for both small and large projects.

Indoor Unit Specifications

Ceiling Mounted Cassette Round Flow & Round Flow with Sensing

Model	Tonnage (TR)	Capacity (kW)	CFM	CMH	BTU/h
ZCRF015	1.5	5.3	388	660	18,100
ZCRF020	2.0	7.1	471	800	24,200
ZCRF025	2.5	8.5	589	1000	29,000
ZCRF030	3.0	9.9	647	1100	33,800
ZCRF036	3.6	11.2	706	1200	38,200
ZCRF040	4.0	12.7	824	1400	43,300

Ceiling Mounted Cassette Corner Type

Model	Tonnage (TR)	Capacity (kW)	CFM	CMH	BTU/h
ZCCC010	1.0	3.2	259	440	10,900
ZCCC015	1.5	4.5	324	550	15,400

Ceiling Mounted Cassette (Compact Multi-Flow) Type

Model	Tonnage (TR)	Capacity (kW)	CFM	CMH	BTU/h
ZCMF010	1.0	3.2	259	440	10,900
ZCMF015	1.5	4.5	324	550	15,400

Ceiling Mounted Cassette (Double Flow) Type

Model	Tonnage (TR)	Capacity (kW)	CFM	CMH	BTU/h
ZCDF020	2.0	7.1	471	800	24,200
ZCDF025	2.5	8.5	589	1000	29,000

Slim Ceiling Mounted Duct Type

Model	Tonnage (TR)	Capacity (kW)	CFM	CMH	BTU/h
ZSCD015	1.5	5.3	388	660	18,100
ZSCD020	2.0	7.1	471	800	24,200
ZSCD025	2.5	8.5	589	1000	29,000

Wall Mounted Type

Model	Tonnage (TR)	Capacity (kW)	CFM	CMH	BTU/h
ZWM010	1.0	3.2	259	440	10,900
ZWM015	1.5	5.3	388	660	18,100
ZWM020	2.0	7.1	471	800	24,200

Ceiling Mounted Duct Type

Model	Tonnage (TR)	Capacity (kW)	CFM	CMH	BTU/h
ZCMD018	1.8	6.2	388	660	21,100
ZCMD024	2.4	8.3	530	900	28,300
ZCMD030	3.0	10.5	647	1100	35,800
ZCMD036	3.6	12.3	765	1300	42,000
ZCMD048	4.8	16.5	1000	1700	56,300

Industry-Leading Warranty

Zusuka proudly offers the World's First 3-Year Warranty for Commercial Air Conditioning:

1 Year Full Unit Warranty
2 Years Extended Compressor Warranty
Total: 3 Years Warranty – A mark of our superior quality and engineering
